Description
- Power Cord - 3x Extra Fader Knob - Original Box ** Item Note: Item powers on but was not fully tested **
- Nominal Input Level (O/P MASTER 0 dBu): CH1, CH2 CD (L, R): -13 dBuCH1, CH2 LN (L, R): -17 dBuCH1, CH2 PH (L, R): -61 dBuCH1, CH2 DVS RETURN (L, R): -13 dBuMIC IN: -40 dBu
- Maximum Input Level: CH1, CH2 CD (L, R): 6 VrmsCH1, CH2 LN (L, R): 6 VrmsCH1, CH2 PH (L, R): 0.04 VrmsCH1, CH2 DVS RETURN (L, R): 6 VrmsMIC IN: 0.6 Vrms
- Maximum Output Level (1 kHz, typ.): OUTPUT MASTER (L, R): +15 dBuOUTPUT BOOTH (L, R): +15 dBuPHONES: 31 mW (1 kHz, typ.)
- Recommended Load Impedance: PHONES: 32 Ohms
